nac Memrecam Acs-3 M16

nac Memrecam Acs-3 M16

Compact and High Performance Camera bringing the next generation of high speed cameras. Perfect for Research and Development (R&D), Defense, Aerospace, and Much More.

  • 1280x896 pixels @25,00fps
  • Ultra High Sensitivity Color ISO 20,000 and Mono ISO 1000,000
  • USB 3.0B For Ultra Fast Download
  • Compact Housing

Features and Specifications
Features
Boost Mode For Increased FPS or Vertical Resolution
Auto Black Balance Mechanical Calibration Shutter
Memory Segment Up to 64 Segments
Built-in SSD

Faster Auto Storage into Built-in SSD

Backup image data while in recording

Faster Download Download via USB3.0B (to PC)
DOWNLOAD REC Recording to a memory segment in parallel with downloading to another memory segment
Image Trigger Triggered by intensity shifts sensed at the minimum area of 21x16 pixel
Dual Framing Rate 1x and 1/2 ~ 1/100x
CAM MODE LED Status LED : READY / VIEW / ARM / REC
SYNC Recording Fully synchronized with GX-HUB

Frame straddling

Shooting

Record continuous 2 pictures for PIV analysis

Support minimum 500ns laser pulse

Fan control Pause control / auto fancontrol / forced cooling mode
Auto pilot Read sequence and execute automatically
EST SYNC Sync with an external signal
Specifications
Sensor 1.14M Pixel, CMOS
Active Pixel 1,280×896
ISO(REI)

ISO 5,000 - 40,000 (color)

ISO 25,000 - 200,000 (Mono)

Electric Shutter

1/100 ~ 1/1,666,666 sec. 1/100 ~ 1/909,090 sec

Memory 16GB / 32GB / 64GB
Memory Segment Up to 64 Segments
Bit Depth 8bit / 10bit / 12bit
Lens Mount

F Mount (Support to Iris ring-less Lens)

C Mount ※1 EF Mount ※1

Video Output DisplayPort/ 3G-SDI(Level A)
Input Signal Trigger(TTL/Contact)/ EST/ IRIG-B/ ARM CMD/ PWR CTL
Output Signal Status(ARM/FAULT)/ Exp. Pulse/ EPO/ Trigger OUT/ VD OUT
Trigger Mode NORMAL/ EVENT/ BURST/ MULTI/ LINEAR
Interface 1000BASE-T / USB3.0B / 3.0 / 2.0
Control PC (V-PAD 11.6” Touch Panel Monitor)
Power 20-32VDC
Dimensions Approx. 128W×128H×206D mm
(without handle)
Weight Approx. 4.5kg
