Macurco TX-12-ND Nitrogen Dioxide NO2 (Line Voltage) Fixed Gas Detector Controller Transducer
Macurco TX-12-ND Nitrogen Dioxide NO2 (Line Voltage) Fixed Gas Detector Controller Transducer
The Macurco TX-12-ND is a line voltage, dual relay Nitrogen Dioxide (NO2) detector, controller and transducer. The TX-12-ND utilizes an internal switching power supply that is capable of using line voltage between 100 and 240VAC and 50-60Hz. The TX-12-ND has selectable 4-20 mA output, buzzer and digital display options. It is an electronic detection system used to measure the concentration of Nitrogen Dioxide and provide feedback and automatic exhaust fan control to help reduce Nitrogen Dioxide concentrations in parking garages, maintenance facilities or other commercial applications. The TX-12-ND is a low level meter capable of detecting from 0-20ppm of Nitrogen Dioxide. The TX-12-ND is factory calibrated and 100% tested for proper operation, but can also be calibrated in the field.
Key Features:
- 100-240VAC input
- 5A SPDT Fan control relay
- 0.5A N.O. or N.C. Alarm Relay
- Selectable Fan and Alarm Relay Actuation Settings
- Digital Display (0-20ppm of NO2), Internal Buzzer
- Coverage Area: 5000 sq. ft.
- 4-20mA current loop
