Order Includes: Process imager Xi, USB cable (1 m), Cable for output/input (1 m) incl. terminal block, Mounting bracket with nut, Software package optris® PIX Connect

A Hybrid Design

The newly developed optris Xi 80 combines the benefits of infrared cameras and infrared thermometers. The Xi 80 is a fusion between a robust, compact pyrometer and an advanced IR camera. The autonomous operation with automatic spot finder function as well as the direct analog output and the affordable price make up a perfect match for the OEM use of the rugged industrial imager.

A full 80x80 thermal image eliminates the hunt for the hot spot and tedious positioning required with single spot temperature sensors. The integrated spot finder function will identify the hottest (or coldest) spot in the image and automatically communicate these measurements without an external PC.

A wide range of optics including the new 80° lens equips the Xi 80 to collect and analyze temperature information over a wide target area.  The affordable pricing for this unit makes it a realistic alternative to replace existing spot temperature sensors or for OEM applications.

Key Features:

• Small sized rugged camera with motorized focus

• Distance-to-spot-size ratio up to 190:1
• Autonomous operation with automatic spot finder
